XZ2860 XCMG HDD Directional Drilling

Max Rotation Torque 90000 N.m
Engine Power 264 Kwx2
Max Push&pull Force 2860 kN
Suitable Pipe Size 127/140/168mm*9.6m
Quantity:
Inquire Add to Basket

XZ2860 XCMG HDD Directional Drilling  Technical specification

Product model:  XZ2860 XCMG HDD Directional Drilling

Manufacturer: XCMG GROUP

XZ2860  XCMG  HDD Directional Drilling  is one-piece and full-drive horizontal directional drilling machine, which can choose the independent operating room. The machine adopts Closed loop circuit, the electro-hydraulic proportional control, load sensitive control, a number of advanced control technology and the company's proprietary technology. The main technical parameters and the  control technology have reached the international advanced level. The main components such as hydraulic system, transmission system, reducer, electric control system choose the international brand-name products with the high reliability.

I. The highlights

1.Digital instrument can automatically display actual torque when working and the push&pull forces. Electronic sensor technology is sensitive and it can timely feedback instantaneous overload, and reliably protect of drilling rig; digital instrument overcomes the inaccurate, slow response, the need for manual gear torque conversion according to the construction and disadvantages of push pull indication of the traditional pressure meter.

2.The drilling frame slip rely on push-pull cylinder. Combining with the front arm drill penetration angle adjusting structure, simple operation, safe and convenient. The three limit impact free limit technology is used to limit the drilling rig.

3.Dual power system, either engine starts can confirm whole working requirement.The XZ2860 XCMG HDD directional drilling can work in different terrain by multi working condition adjust technology and multi-gears control syste on rotation and push&pull.If the small diameter channel construction needed,only one engine start can save fuel and reduce the cost.

4.Full floating vise,high torque shackle clamp make laying up sleeve pipe easily.The patent rotation vise seat make it easy to find center and clamp tightly.

5.Overload protection technology, drilling rig rotary torque, push&pull and clamping vice  are using digital pressure regulating technology, convenient adjustment, simple and accurate preset.

6.Closed Rotating hydraulic system, Sensitive loading controlled push&pull with international well-known brand components such as hydraulic,electronic device and transmission device make quality reliable.

II. The introduction of technology

1. Chassis

XZ2860  XCMG HDD Directional Drilling  adopts the steel tracks and venue with the strong adaptability and high reliability. Import walking speed reducer is stable and reliable.

Track length 4025mm
Track external rim distance 2750mm
Track width 600mm
Wheel base 2150mm
Supporting roller No. 9 pcs * 2
Walking reducer Germany Rexroth GFT60 * 2
Driving force 322kN
Gradability 30%
Walking speed 1.5km/h
Ground pressure 96.1kPa
Operating weight 48T(ZX2860 Plus)

2. Engine System

Choosing Cummins turbo engine. It is powerful. Meeting the China's second/third(Standard option) stage emission standards.

Engine type QSL8.9-C360(3 stage)/6LTAA8.9-C360(2 stage)
Rated power 264kW×2
Max. torque 1500 N.m /（1500r/min）(QSL8.9)
1400N·m /（1400r/min）(6LTAA8.9)
Standard Third /Second stage
Main engine fuel tank volume 900L

3. Hydraulic system

Rotating takes the closed hydraulic system. Push and pull takes the load sensitive control and other advanced control technology.T he imported components are reliable in quality.

Power head rotation system
Rotation pump SauerH1PX2
Pressure 330bar
Motor Rexroth  A6V×6
Power head push and pull system
push and pull pump SauerERX4
Pressure 310bar
Motor Rexroth  A6V×8(XZ2860)
Rexroth  A6V×10(XZ2860 Plus)
The hydraulic oil tank volume 940L
The hydraulic oil Caltex HD46 (normal -15 ℃ to -40 ℃,  standard)
Caltex HDZ46 (cold, - 30 ℃ to 40 ℃)

4. The electrical system

According to the characteristics of the horizontal directional drilling construction, the application of advanced intelligent control technology, CAN bus technology, the instrument shows clear. It is convenient to observe.

Using large size, high resolution display. Automatic directly show the actual construction of the push pull force and rotary torque.

PLC control has the engine speed, water temperature, oil pressure, hydraulic oil temperature, oil filter, power head limit and other parameters can monitor and alarm with the fault self-diagnosis function and convenient maintenance.

Walking wire control, stepless speed regulation. It is convenient to operate.

Rotation and push-pull adopt multiple control, stepless speed regulation, suitable for wide scope of strata and geological.

System voltage DC24V
Storage battery Delphi6-QW-120B X4
Controller RexrothRC28-14/30
Display PalfinTT104V2-L
Push and pull rotation handle Sauer MCH22
Speed sensor RexrothHDD2L16NA/20
Induction switch HoneywellJM18APA102
Travel switch HoneywellSZL-WLC-B
Temperature sensor DanfossMBT3270020
Pressure sensor DanfossMBS3050

5. Drill stand

Use rocker arm before and the rear range at the same time, the support cylinder Angle adjustment scope of the operation is simple and large scope.

Equipped with the identity of the welded drill, standard pipe bracket, it is convenient to operate. Drill sliding is driven by oil cylinder and it is convenient to adjust..

Drill sliding distance 2500mm
Drill stand Angle adjustment 8～16°

6.Power head

The drilling machine can finish the action of push and pull through the gear and rack. Power head floating mandrel device can effectively protect the drill pipe thread. The variable motor can achieve high-speed push-pull. The size of push an pull can be adjusted according to the requirements of the construction of inorganic, which can protect the drill pipe.

Max. Push& pull force 2860kN(XZ2860)
Max. Push&pull speed 25m/min
Max. rotating torque 90000N.m(XZ2860)
Max. Rotating speed 95r/min(XZ2860)
Max. walking distance 11500mm(XZ2860)
Rotating reducer BreviniED2090/Bonfiglioli 307L2(XZ2860)
Push and pull reducer BreviniET3250/Bonfiglioli 310L3

7. Vice

XZ2860 XCMG HDD directional drilling equipped with three cylinder strength shackle vice, it can move in the drill on the whole. It is convenient to construct. The front and rear vice can relative slip. It is easy to maintenance and replace the saber tooth.

Shackle torque 262250N•m
Rear vice rotation angle 21°
Vice separation distance 300mm

8. Lorry-mounted crane

Random configuration: 3.2 t lorry crane. It is stable and convenient to operate according to the  manual.

Maximum lifting weight 3.2T
Maximum working range 6.32m
Maximum lifting moment 6t•m

9. Cabin

Lift control cab, adjustable seats, equipped with air conditioning, greatly improved the operation comfort level of drilling rig, interior lights, windshield wipers, shade screens, shock absorption seats, such as configuration, suitable for operation.

10. Independent operating room (Option)

Equipped with the independent air conditioning room, where the operator is away from the vibration and noise of drilling and is comfortable to operate. The machine is equipped with the independent operating room and cannot be installed by the cabin.

 Input power 220V
Operating room size (L X W X H mm) 3500X2438X2591
Air conditioning power   1.5P

11. Drill pipe(Option)

The users can choose standard oil drill pipe or special double top type trenchless pipe. The expansion can choose cut back expansion type, expanding type, port type or other special reamer, whose diameter are from 300 mm to 1600 mm. Users can also choose other types and specifications of the short connection and transfer according to their own needs.

Note: the biggest hole diameter and the the longest distance of construction is associated with the specific construction formation.

Drill pipe diameter Φ140mm
Drill pipe length 9600mm
Two ends of drill pipe joint size 5-1/2FH

III. The main technical parameters

Item Unit Quality
Power station engine Producer   Cummins
Type   QSL8.9
Rated power kW/ rpm 528 (264X2)/2100 kW/ r/min（QSL8.9， standard）
Push and pull Type   Eight  motor drive gear and rack type(XZ2860)
Eight  motor drive gear and rack type(XZ2860 Plus)
Biggest drag/feed force kN 2860/2860(XZ2860)
3600/3600(XZ2860 Plus)
Power head speed m/min 0～25
Rotary Type   Five motor drive gear transmission
Power head maximum torque N.m 90000(XZ2860)/110000(XZ2860Plus)
Power head rotation speed r/min 0～95(XZ2860)/0~76(XZ2860Plus)
Drill stand Type   Sliding box drill stand
Adjustable angle ° 8～16
Lorry-mounted crane Type   Rotary arm straight telescopic crane
Maximum lifting quality t 3.2
Walking drive Type   Steel crawler self-propelled
Walking speed km/h 1.5
Slurry pump Type   Independent pump station(outside)
 Dimension mm 17500X3200X3550
Host weight t 46t(XZ2860/48T(XZ2860Plus)

IV. The main component configuration

Engine Cummins
Rotary pump Sauer
Push and pull pump Sauer
Rotary motor Rexroth
Rotary reducer Brevini/Bonfiglioli
Push&pull motor Rexroth
Push and pull reducer Brevini/Bonfiglioli
Controller Rexroth
Main valve Sauer
Pilot Sauer
Track Xiangong, Hubei province
Walking reducer Rexroth
Lorry-mounted crane XCMG
Hose coupler XCMG
Oil cylinder XCMG

V. The Machine Appearance And Transportation

xcmg HDD directional drilling 1

Dimension 17500×3200×3550
Weight 46T(XZ2860)/48T(XZ2860Plus)

VI. The Transportation Plan

To meet the requirements of highway transportation, the host is dismantled two parts to transport. The car engine, hangar, rocker arm, fuel tank, hydraulic oil tank, carriage, rocker arm and other parts in the upper cars. The drill body, power head, vice, anchor, lorry crane and other parts in the below cars.

xcmg HDD directional drilling 2

The upper car’s dimension 17500X2400X2250
Weight 25T

xcmg HDD directional drilling 3

The below car’s dimension 9500X2950X3550
Weight 21T

VII. The documents

XZ2860 XCMG HDD Directional Drilling technical documents as the following:

Product certificate
Product specification
The engine maintenance manual
The machine operation instruction
Lorry-mounted crane operation instructions and maintenance manual
Mud pump maintenance manual (Option)
Packing list (Including wearing parts and spare parts list, the accessory tools list)
