| Quantity: | |
|---|---|
| Description | Unit | FMYG260-8 | |
| Operating weight | kg | 18000 | |
| Length×Width×Height | mm | 13100×2570×2880 | |
| Engine | Model | Yuchai | YC6B125 |
| Rated power/speed | kw/r/min | 92/2200(125hp) | |
| Max Torque | N.m | 463 | |
| Piston displacement | L | 6.871 | |
| Fuel consumption | g/kw.h | ≤240 | |
| Fuel tank capacity | L | 160 | |
| Hydraulic system | Main pump | Kawasaki | K3V63DT |
| Rated flow | L/min | 2×120+30 | |
| Implementation circuit | MPa | 31.5 | |
| Hydraulic oil tank capacity | L | 200 | |
| main valve | Parker | AV170 | |
| Hydraulic motor | Travel motor | DOOSAN | TM22 |
| Swing motor | Korea Advance | SDS140C | |
| Specification | Swing motor | r/min | 11 |
| Max. Traction force | kN | 83 | |
| Traveling speed | km/h | 2.5--4.5 | |
| Grade ability | ° | 28 | |
| Ground pressure | kPa | 37.3 | |
| Cab | Dimensions | mm | 1800x990x1620 |
| Rotary support | Diameter | mm | 1122 |
| Bucket capacity | M3 | 0.8 | |
| Working weight | Kg | 19800 | |
| Swing speed | rpm | 12 | |
| Travel speed | Land | Km/h | 4.2 |
| Swamp | Km/h | 2.3 | |
| Hydrostatic | Km/h | 1.8 | |
| Max Gradient | ° | 30 | |
| Ground pressure | Kpa | 18.4 | |
| Bucket digging force | KN | 81.3 | |
| Max. digging radius | mm | 8260 | |
| Max. digging depth | mm | 5180 | |
| Maximum digging height | mm | 9040 | |
| Max. discharge height | mm | 6620 | |
| Min. turning radius | mm | 3450 | |
| Description | Unit | FMYG260-8 | |
| Operating weight | kg | 18000 | |
| Length×Width×Height | mm | 13100×2570×2880 | |
| Engine | Model | Yuchai | YC6B125 |
| Rated power/speed | kw/r/min | 92/2200(125hp) | |
| Max Torque | N.m | 463 | |
| Piston displacement | L | 6.871 | |
| Fuel consumption | g/kw.h | ≤240 | |
| Fuel tank capacity | L | 160 | |
| Hydraulic system | Main pump | Kawasaki | K3V63DT |
| Rated flow | L/min | 2×120+30 | |
| Implementation circuit | MPa | 31.5 | |
| Hydraulic oil tank capacity | L | 200 | |
| main valve | Parker | AV170 | |
| Hydraulic motor | Travel motor | DOOSAN | TM22 |
| Swing motor | Korea Advance | SDS140C | |
| Specification | Swing motor | r/min | 11 |
| Max. Traction force | kN | 83 | |
| Traveling speed | km/h | 2.5--4.5 | |
| Grade ability | ° | 28 | |
| Ground pressure | kPa | 37.3 | |
| Cab | Dimensions | mm | 1800x990x1620 |
| Rotary support | Diameter | mm | 1122 |
| Bucket capacity | M3 | 0.8 | |
| Working weight | Kg | 19800 | |
| Swing speed | rpm | 12 | |
| Travel speed | Land | Km/h | 4.2 |
| Swamp | Km/h | 2.3 | |
| Hydrostatic | Km/h | 1.8 | |
| Max Gradient | ° | 30 | |
| Ground pressure | Kpa | 18.4 | |
| Bucket digging force | KN | 81.3 | |
| Max. digging radius | mm | 8260 | |
| Max. digging depth | mm | 5180 | |
| Maximum digging height | mm | 9040 | |
| Max. discharge height | mm | 6620 | |
| Min. turning radius | mm | 3450 | |
