| Quantity: | |
|---|---|
| Description | Unit | FMYG180--7 | |
| Operating weight | kg | 16600 | |
| Bucket capacity | M3 | 0.8 | |
| Length×Width×Height | mm | 7950×2570×2880 | |
| Engine | Model | Yuchai | YC6B125 |
| Rated power/speed | kw/r/min | 92/2200 (125hp) | |
| Max Torque | N.m | 463 | |
| Piston displacement | L | 6.871 | |
| Fuel consumption | g/kw.h | ≤240 | |
| Fuel tank capacity | L | 160 | |
| Hydraulic system | Main pump | Kawasaki | K3V |
| Rated flow | L/min | 2×120+30 | |
| Implementation circuit | MPa | 31.5 | |
| Hydraulic oil tank capacity | L | 200 | |
| Hydraulic motor | Travel motor | Korea Doosan | TM |
| Swing motor | Korea Advanced | SDS | |
| Specification | Swing motor | r/min | 12 |
| Bucket digging force | kN | 70 | |
| Arm digging force | kN | 58 | |
| Max. Traction force | kN | 83 | |
| Traveling speed | km/h | 2--5.5 | |
| Grade ability | ° | 30 | |
| Ground pressure | kPa | 34.5 | |
| Main dimensions (mm) | FMYG180--7 |
| Upper full width (including car pedal) | 2490 |
| The cab full width | 960 |
| Bridge all high | 2830 |
| Radius of gyration platform | 2200 |
| Level of balancing | 920 |
| The minimum clearance from the ground | 440 |
| Guide wheel and driving wheel center distance | 2780 |
| Track length | 3800 |
| Track width | 1940 |
| Track width | 600 |
| Equipped with 600 mm segments of caterpillar full width | 2520 |
| The scope of work (mm) | FMYG180-7 |
| Movable arm length | 4700 |
| Arm length | 2500 |
| The largest mining range | 8260 |
| Surface biggest mining area | 8110 |
| MAX digging dept | 5600 |
| MAX digging height | 8700 |
| MAX dumping height | 6500 |
| The maximum vertical wall depth can be found | 5070 |
| Eight feet level maximum digging depth | 5380 |
