XCMG RP803 concrete asphalt paver 8000mm paving width
| Item | Unit | RP803 |
| Basic paving width | m | 3 |
| Max. paving width | m | 8 |
| Max. paving thickness | mm | 380 |
| Paving speed | m/min | 0~14 |
| Travel speed | km/h | 0~3.0 |
| Theoretical productivity | t/h | 600 |
| Hopper capacity | t | 13 |
| Gradeability | % | 20 |
| Pavement evenness | mm/3m | 3 |
| Cross slope error | % | +/- 0.03 |
| Crown adjustment range | % | 0~3 |
| Diesel engine model |
| BF4M1013C |
| Diesel engine power | kw | 118 |
| Diesel engine speed | r/min | 2300 |
| Diesel oil tank capacity | L | 230 |
| Overall weight | t | 16.5~23.5 |
| Dimension | mm | 6230X3000X3855 |
| Vibration frequency | Hz | 68~71 |
| Screed heating mode |
|
|
| Material level control mode |
|
|
| Automatic Leveling Control |
|
|
| Item | Unit |
| Screed model | 575(RP802) |
| Type | Vibrating tamper, vibration, electrical heating |
| Stretch mode | Hydraulic stretch |
| Width range | 3.0-8.0m |
| Vibrating tamper rotate speed | 0-1500r/min |
| Vibration frequency | 4mm |
